Rated for Miami-Dade at 60 PSF design load and maximum glass length of 10' Rated for Florida State Product approval for non impact glass as well as impact-rated glass, restricted to vertical orientation only Colors: View Design Options tab for more details Colors: View Design Options for more details Polycarbonate laminated to the interior surface of the glass Allows passage of light while maintaining privacy May be insulated with Lumira® aerogel insulation, for energy efficiency Hurricane-rated small missile impact resistant channel glass system for 30 feet or higher above ground level also available Sound insulation (up to 42 db uninsulated, 44 db with Lumira aerogel insulation) Aluminum perimeter frame provides additional structural strength 70-75% (varies with coating and insulation) .50 (uninsulated), .34 (with 16 mm Lumira® aerogel insulation), .28 (with 25 mm Lumira aerogel insulation) 42 dB (uninsulated), 44 dB (with Lumira aerogel insulation)

Pilkington Profilit Hurricane can be filled with Lumira® aerogel, a new class of lightweight insulation material produced by Cabot Corporation which is ideally suited for daylighting design. The exceptional thermal performance of Lumira aerogel helps increase energy efficiency. Lumira aerogel also promotes soft, even light dispersion, reduces unwanted noise and resists condensation.  TGP is the exclusive supplier of Lumira aerogel for channel glass systems. Eliminates glare, allows soft, even, light dispersion Reduces heat loss and minimizes solar heat gain Maintains performance over time Prohibits growth of mold, mildew and fungus Reduces building design loads and conserves energy Meets and exceeds strict building codes See Pilkington Profilit Insulation product page for more information. Slightly dimpled surface with Pilkington Profilit™ Hurricane is also available in a variety of glass textures, glass colors and back-applied polycarbonate combinations:

Antisol® -standard cast texture with a bronze solar coating Amethyst -standard cast texture with a translucent blue coating Pilkington Profilit OW (low-iron) -standard cast texture, nearly colorless Pilkington Profilit OW Macro (low-iron) -netted screen surface texture, nearly colorless A variety of polycarbonate color options To view non-hurricane rated samples of these color options, visit Pilkington Profilit. Due to individual computer monitor limitations, colors and textures seen here may not accurately reflect Pilkington Profilit products. To confirm color or texture choices for your project, please contact Technical Glass Products. Envision what Pilkington Profilit looks like in a real-world setting. Use our innovative Texture Module to view available textures and finish options. See what Pilkington Profilit looks like up close, as well as a representation of how it affects the light and alters the view in a room. Pilkington Profilit Hurricane should be installed in accordance with approved shop drawings – plumb, level, square and free from warp or twist while maintaining dimensional tolerances and alignment with surrounding construction.

Erect framing, vinyl spacer and glass in accordance with manufacturer’s printed installation instructions. Seal glass units continuously on both sides of glass between frame and glass and between linear glass units. Install perimeter joint sealant and backing materials between assemblies and adjacent construction.jcpenney hilton curtains Pilkington Profilit Hurricane has been tested to meet the following standards: Miami/Dade County, NOA number 06-0810.12, TAS 201, TAS 202, TAS 203, Florida State Product approval # FL 10792, AAMA 501.4, AAMA 101, AAMA 1801-97, AAMA/NWWDA 101/1, S.297, ASTM F 588-97, NFRC 100-97, ANSIZ97.1-1984, CPSC 16CFR 1201, Category II. download lagu blue curtain fallsAll testing carried out by Architectural Testing Inc., York, PA.; yorkshire linen blackout curtains

Fenestration Testing Labs, Medley, FL; and ETC Labs, Rochester, NY. Formal test results are available by contacting Technical Glass Products. Note: Exceptions to hurricane rating approval include horizontally glazed orientation, radius, serpentine and all glass corner configurations.thomas the tank engine blackout curtains Please see our complete 3-part CSI format Pilkington Profilit Hurricane specifications.cream red curtains 90x90 Technical Glass Products can also offer project specific assistance upon request.curtains glasnevin To obtain CAD details for Pilkington Profilit, please use our CAD request form.hookless shower curtain cheap

Download a PDF of our Care & Warranty Brochure. Whenever possible, double channel frames that accommodate both the stained glass windows and their protective glazing should be used. Their use facilitates the installation, and any future removals, of either glass panel without affecting the other. We recommend the frames of the J. Sussman Company. Aesthetically, these frames are preferential as well, since retrofitted “storefront” frames become wider with the necessary framing add-ons. This increased visual mass is more intrusive on the stained glass design than the double channel frames. It is also more expensive to retrofit “storefronts” than to use the double channel frames from the beginning. This thermally broken, double channel frame accommodates both thermopane and stained glass. Thermopanes are installed from the exterior of the structure, while the stained glass is installed from the interior. Neither glass panel need be removed to access the other-- an important consideration should repair work ever be needed.

These frames are also the most energy efficient available. Although thermopanes can be very large, stained glass windows cannot, generally not exceeding 14 linear perimeter feet. This frame is built with mullions that subdivide the overall artglass into smaller sized units. Almost any curtain wall or storefront style frame can be retrofitted to accommodate stained glass.  This involves attaching low-profile stained glass frames to the sides of the storefront frames. Although this is an easy way to install stained glass windows to existing windows, it is definitely not the preferred method for new construction. This is because retrofitting storefront frames is very time intensive (expensive) and increases the visual mass of the frames (visually cumbersome; quite intrusive upon the stained glass).  For new construction, always use the double channel frames shown above. Single channel glazing is used in a retrofit situation where exterior protective glazing already exists, and a stained glass channel was not provided for.

Stained glass should never be installed as single glazing against the elements. Although thermopanes can be very large, stained glass windows cannot. A new frame is built with mullions that subdivide the overall artglass into smaller sized units. This frame is then installed inside the existing frame. Installing into wood frames is most commonly found in residential locations. As illustrated, the main requirement is a spacer trim, generally 1/2"- 3/4" wide to separate the stained glass from the thermopane. As with any stained glass window, each individual panel should not exceed 14 linear perimeter feet. Kessler Studios adheres to the rule-of-thumb concept that no single stained glass panel should exceed 14 linear perimeter feet. This means that one should be able to measure the perimeter of each stained glass panel and that total should be less than 14 feet in length. Keeping panels within this size ensures that the windows will be structurally sound. Here is an example of an existing curtain wall with many large exterior thermopanes.

Note the units along the top. The stained glass panels could not be built so large, so add-on frames were specified. The ideal situation would have been to originally use a double channel frame, such as Sussman 5600 with built-in divisional mullions. This approach would have minimized the visual intrusion of add-on frames. Here is the project with the add-on frames and artglass installed. In some sections the windows were divided into as many as three panels. Stained glass is so demanding of attention that the additional structural elements go virtually unnoticed. It is nearly impossible to give a general weight for finished stained glass panels. Aside from the overall size of a panel, another factor is the lead came which comes in many sizes. Kessler Studios uses various lead widths to add an expressive element to the design. Thus, while a very simple design might top out at 2-3 pounds per square foot, a complex panel might weigh 4-5 pounds per square foot, or more.
